Details

The Nokia FastMile 5G Gateway is a single indoor device that is easy to install and connects wirelessly to the mobile network. It comes with carrier aggregation, the gateway improves performance and reliability by using the best available 4G and 5G signals.

It is a plug-and-play solution that is simple to install and uses a visual guide to assist customers in identifying the right location in the home to achieve the best performance. The gadgets compatibility with the Nokia in-home Wi-Fi solution provides a seamless ultra-broadband experience in every corner of the home.

The Nokia FastMile 5G Gateway maximizes spectral assets and uses the higher gain antenna to deliver up to twice the indoor coverage, three times the downlink capacity, and five times the uplink capacity compared to other traditional devices. High-gain antennas can deliver brilliant broadband even in rural areas.

Features

5G high gain antenna, automated antenna alignment, gain in n78: 11 dBi maximum
High-gain antennas can deliver brilliant broadband even in rural areas
Multiband omni antenna for LTE
Integrated residential gateway
Central point of mesh network with Nokia WiFi Beacon 3s
Fully self-contained, full featured indoor residential gateway
5G New Radio (NR) WAN connection with 11 dBi high gain antenna
4G WAN
Carrier aggregation across supported 4G/5G bands
2.5 Gigabit Ethernet (GigE) WAN
3 GigE LAN
Wi-Fi (3x3 802.11b/g/n, 4x4 802.11ac MU-MIMO) LAN
Visual cues guide the consumer to the optimal location for 5G performance in the home
Delivers gigabit home services with 5G NR
Automatic 5G antenna alignment ensures maximum signal and minimal noise
High gain antenna maximizes performance and conserves spectral assets
Reduced deployment costs with subscriber self-installation
Extends 5G speeds throughout the home with Nokia WiFi beacons
Part of Nokia end-to-end 5G solution

Specifications

Physical	Height: 240 mm (9.4 in) Width: 140 mm (5.5 in) Weight: 2.2 kg (4.9 lb)
Operating environment	Temperature: 0°C to 45°C (32°F to 113°F)
Power requirements	12 V DC Consumption: 41 W maximum DC power supply
Network terminations	Cellular WAN – 5G NR (3GPP) – 4G/Long Term Evolution (LTE) – SIM slot (size: 4FF/nano) 2.5 GigE WAN
Connectivity interfaces	Wi-Fi (802.11b/g/n, 802.11ac) Three RJ-45 GigE LAN ports USB 3.0 Type A port
Radio – cellular	3GPP, release December 15 – 5G NR NonStandalone (NSA) option 3a, 3x • 5G NR interface band n78 TD 3500 MHz (3300 MHz – 3800 MHz) • Dual connectivity (EN-DC) – 1 LTE + DC 5G (1+n78, 3+n78, 7+n78, 28+n78) – 2 LTE + DC 5G (1+3+n78, 1+7+n78, 3+7+n78) – 3 LTE + DC 5G (1+3+7+n78) • Downlink (DL) 4x4 multiple input, multiple output (MIMO) and 256 QAM • Uplink (UL) 1x1 single input, single output (SISO) and 64 QAM • Supported carrier bandwidths – 5G: 20 MHz, 40 MHz, 60 MHz, 80 MHz, 100 MHz – 4G/LTE: 5 MHz, 10 MHz, 15 MHz, 20 MHz • FDD B1 (2100 MHz), B3 (1800 MHz), B7 (2600 MHz), B28 (700 MHz), TDD B40 (2300 MHz) • Extensive carrier aggregation between supported bands
Radio – Wi-Fi	Dual-band concurrent IEEE 802.11b/g/n 3x3 2.4 GHz and 802.11ac 4x4 5 GHz Mesh topology with Nokia WiFi Beacon 3s Seamless roaming (IEEE 802.11k, 802.11v)
Security	Adheres to strict Nokia security standards Wi-Fi Protected Access (WPA) support, including WPA Pre-Shared Key (PSK) and WPA2
Management	Multicolor LEDs for status view Web user interface (WUI) for local configurations TR-69 auto-configuration server (ACS) access for remote device management
Buttons	Power on/off Wi-Fi Protected Setup (WPS) Reset
Regulatory compliance	CE and RCM

5G high gain antenna
High-gain antennas delivers brilliant broadband even in rural areas
Multiband omni antenna for LTE
Integrated residential gateway
Carrier aggregation across supported 4G/5G bands
2.5 Gigabit Ethernet (GigE) WAN
